Product Description
Support Cameras:
TVI: 1080P (1920×1080), 960P (1280×960), 720P (1280×720)
CVI :1080P (1920×1080), 960P (1280×960), 720P (1280×720)
AHD :1080P (1920×1080), 960P (1280×960), 720P (1280×720)
For the environment:
Security Systems
Radio and television transmission
HD Video monitoring
Building control systems
Train/High speed road monitoring
Intelligent Traffic Monitoring System (ITS)
Remote multimedia teaching / campus monitoring
Long-distance radio and television transmission system
Optical index:
1.Optical Interface : FC
2.Fiber optic: Single-mode (9/125μm), Multimode 50/125um ,62.5/125μm
3.Wavelength: 1310/1550μm
4.Transmission distance: single-mode fiber 0-20KM, Multi mode fiber 0~500meters
Video Index:
1.Video : 4 channels
2.Video Interface: BNC
3.Support 1280×720, 1280×960,1920×1080 @25Hz, @30Hz,@50Hz,@60HZ
4.Coaxial cable transmission length: 1080p up to 300meters.720p up to 500meters
5.Video Input / Output Impedance : 75ohm ( unbalanced ) ;
6.Video Bandwidth 100MHz;
7.Video format compatible PAL, NTSC, SECAM;
