HIKVISION DS-3E0510HP-E PoE Network Switch Unmanaged Gigabit Ethernet (10/100/1000)

8 Port Gigabit Unmanaged POE Switch
6 × gigabit PoE ports, 2 × gigabit Hi-PoE ports, 1 × gigabit RJ45 port, and 1 × gigabit fiber optical port.
IEEE 802.3at/af/bt standard for Hi-PoE ports (Max. 90 W PoE output).
IEEE 802.3at/af standard for PoE ports (Max. 30 W PoE output).
IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z standard.
6 KV surge protection for PoE ports.
Up to 300 m long-range transmission.
PoE watchdog to auto detect and restart the cameras that do not respond.
Port isolation to improve network security.
Gigabit network access design.
Wire-speed forwarding.
Store-and-forward switching.
Solid high-strength metal shell.
Reliable fan-free design.
Brand: HIKVision
Warranty: 1 Year Warranty
Availability: In Stock
Rs. 27,500

Product description

Description Product Details Data Sheet Further details Download NETWORK SWITCH 10 ETHERNET PORTS - 6 GIGABIT PoE PORTS - 1 GIGABIT RJ45 PORT - 2 GIGABIT HI-POE PORTS - 1 GIGABIT SFP OPTICAL PORT - HIKE - DS-3E 0510H00P-E
Ethernet Switch - Hikvision - DS-3E0510HP-E
10 ports - 6 GIGABIT PoE ports - 1 GIGABIT RJ45 port - 1 SFP fiber port - 1 Hi-PoE Gigabit port - Mac address 4K - 20 Gbps switching capacity - 1.5 Mbit internal cache - Metal-finished shell for maximum strength - Transmission data up to 300 m - Fan terterloses design - terterE Watchdog - 6 kV lightning protection - Hikvision - DS-3E0510HP-E Product details Network Switch - Hikvision - DS-3E0510HP-E
10 total doors.
6 GIGABIT PoE ports
2 GIGABIT Hi-PoE ports
1 GIGABIT RJ45 connector
1 GIGABIT SFP fiber optic connector
Supported standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z
Supported PoE standards: IEEE 802.3af, IEEE 802.3at
MAC Table Size 4K
Door insulation for safety reasons
PoE watchdog function.
Metal - no fans equipped
6KV lightning protection.
Remote transmission up to 300 m.
Dimensions: 217.6 mm x 108.55 mm x 27.8 mm (8.57 x 4.27 x 1.09 inches).
Datasheet Model DS-3E0510HP-E network parameters port number 6 × Gigabit PoE ports, 2 × Gigabit Hi-PoE ports, 1 × Gigabit RJ45 port and 1 × Gigabit fiber port type RJ45 port, full duplex, MDI/MDI-X adaptive standard IEEE 802.3, IEEE 802 IE.3u, IEEE 802.3x, IEEE 802.3ab and IEEE 802.3z forwarding mode store and forward switching working mode standard mode (standard), expansion mode, isolation mode, PoE watchdog mode ports for remote transmission, ports 7 and 8 MAC address table 4 K. Switching capacity 20 Gbps packet forwarding. RRRR14,88 Mpps Internal Cache 1.5 Mbit PoE Power Supply Standard PoE Ports 1 and 2: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Ports 3 to 8: IEEE 802.3af, IEEE 802.3at
