Motion Detection 2.0
Human/Vehicle Analysis: 1-ch;4-ch
Recording
Stream Type: Video, Video & Audio
Video And Audio
IP Video Input: 4-ch
Incoming Bandwidth: 40 Mbps
Outgoing Bandwidth: 80 Mbps
HDMI Output: 1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz
VGA Output: 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode: HDMI/VGA simultaneous output
Audio Output: 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1kΩ)
Decoding
Decoding Format: H.265+/H.265/H.264+/H.264
Recording Resolution: 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/ 720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback: 4-ch
Decoding Capability: 1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps) *: The length or width of camera resolution (each track) cannot exceed 4096 pixels.
Network
Remote Connection: 32
Network Protocol: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
Network Interface: 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
PoE
Interface: 4-ch, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power: ≤ 50 W
Standard: IEEE 802.3 af/at
Auxiliary Interface
SATA: 1 SATA interface
Capacity: Up to 8 TB capacity for each disk
USB Interface: 2 × USB 2.0
Alarm In/Out: N/A (4/1 is optional)
General
Power Supply: 48 VDC, 1.35 A
Consumption: ≤ 10 W (without HDD and PoE off)
Dimension (W × D × H): 320 × 240 × 48 mm (12.4" × 9.4" × 1.9")
Weight: ≤ 1.18 kg (without HDD, 2.6 lb.)
